| 1: | Frequency operation range SAT: 950-2150 Mhz | 2: | Frequency operation range TERR: 47-870 Mhz |
|---|---|---|---|
| 3: | Gain adjustment: 20 dB | 4: | TERR gain: 19.....23 dB (4 dB equalizier) |
| 5: | SAT-SAT ısolation: >43 dB | 6: | SAT-TERR Isolation: >50 dB |
| 7: | Max. signal out SAT: 110 dBµV | 8: | SAT + TERR in: 12+1 |
| 9: | SAT + TERR out: 13 | 10: | Operation voltage: 16v 1,5A |
| 11: | Total current: 400 mA | 12: | Total current with LNB: 880 mA |
| 13: | Operation temperature: -20 +50ºC | 14: | Dimensions: 310x120x42mm |
| 15: | Weight: 840gr |
