| 1: | Frequency operation range SAT: 950-2150 Mhz | 2: | Frequency operation range TERR: 47-870 Mhz |
|---|---|---|---|
| 3: | Gain adjustment: 20 dB | 4: | TERR Gain: -1 dB±1 |
| 5: | SAT Gain: 19...23 dB (4 dB equalizer) | 6: | SAT-SAT Isolation: >43 dB |
| 7: | SAT-TERR Isolation: >50 dB | 8: | Max. signal out SAT: 110 dBµV |
| 9: | SAT + TERR in: 9+1 | 10: | SAT + TERR out: 10 |
| 11: | Operation voltage: 16v 1,5A | 12: | Total current: 310 mA |
| 13: | Total current with LNB: 760 mA | 14: | Operation tempature: -20 +50ºC |
| 15: | Dİmensions:246x120x42mm | 16: | Weight: 680gr |
Kaskat kazanç yükselteci,
Yüksek çıkış seviyesi,
Ayarlanabilir kazanç,
LNB ON OFF anahtarı,
Kısa devre koruma,
Yüksek izalosyon
